Product Details:
|
| Product Name: | Heated Air Curtains / Air Curtain With PTC | Cover Material: | Metal Casing |
|---|---|---|---|
| Fan Type: | Cross Flow Fan | Voltage: | 220V Single Phase / 380V Three Phase |
| Air Flow: | 1800 CFM | Voltage/ Frequency: | 220V Or 380V |
| Control: | Button Or Remote Control | Fan Material: | Aluminum Blower |
| Heater: | PTC Heater & Heating Tube For Options | Application: | For Office Buliding , Entryway , Door Head / Shopping Store / Super-Market |
| High Light: | PTC Heated Door Air Curtain,1800 CFM Heated Door Air Curtain |
||
110V / 60Hz , 110V / 50Hz , 220V / 60Hz are all available
| Model | Voltage/ Frequency | Input Power |
Air
|
Air Volume | Noise | Fuselage Size | Mounting Height | |
| (V/Hz) | motor (w) | Heater (KW) |
(m/s) | (m³/h)/CFM | (dB) | (mm) | (m) | |
| RM-1209N-D/Y | 380/50 | 150 | 3.5 | 7-8 | 1000/588 | ≤45 | 900×220×195 | 2.5 |
| RM-1210N-D/Y | 380/50 | 180 | 4.5 | 7-8 | 1100/647 | ≤45 | 1000×220×195 | 2.5 |
| RM-1212N-D/Y | 380/50 | 180 | 4.5 | 7-8 | 1500/822 | ≤47 | 1200×220×195 | 2.5 |
| RM-1215N-D/Y | 380/50 | 220 | 5.5 | 7-8 | 1800/1059 | ≤47 | 1500×220×195 | 2.5 |
| RM-1218N-D/Y | 380/50 | 280 | 8 | 7-8 | 2160/1271 | ≤49 | 1800×220×195 | 2.5 |
| RM-1220N-D/Y | 380/50 | 320 | 10 | 7-8 | 2400/1412 | ≤51 | 2000×220×195 | 2.5 |
Heated Air Curtain Application
Hotel / Reading room / Libraries / Waiting room / Airport / Coffee shop / Bar / Restaurant / Hospital
Remote control applicable to replace manual control
Long distance remote easily control
Invisible air door builds effective barrier / Reduce inside temperature loss
Non-charged PTC heater
PTC heater can be disassembled and cleaned separately, automatic delay when power off ,
PTC heater has high power, large heat, no electricity on the surface safe runing .
Heated Air Curtains -- Product Parameter
What is the main functions of Air Curtain?
1. Heat air curtain
2. Odor isolation
3. Dust-proof, insect prevention
4. Energy conservation
Contact us to have more professional answers.
